Cp-32 bottle washing machine

summary:

Cp-32 bottle washing machine produced by our factory is a new type of bottle washing machine which combines the structure principle of bottle washing machine at home and abroad and according to the actual requirements of users. This machine is a necessary equipment before liquid filling. The water distribution valve is made of non polluting materials, which meets the requirements of food equipment.

Features of the machine:

1、 Spray on the outer wall of the bottle, wash the inner wall, and clean the bottle.

2、 The low-pressure pump is used to pressurize and cycle the bottle, and the water consumption is low.

3、 Simple structure, convenient maintenance, stainless steel water tank, beautiful and generous, corrosion resistance.

4、 It has the advantages of labor saving, high production efficiency and wide applicable bottle types.

Bottle washing principle:

1、 The outer wall of the bottle is sprayed by a spray nozzle, and the spray pressure can be adjusted by the spray switch. (the pressure of the external water source of the machine should be higher than 0.1MPa. If it is lower than this pressure, you need to provide a pressure pump. )

2、 When the inner wall is flushed, the lower valve body is still fixed on the bracket, and the upper valve body is integrated with the upper plate of the bottle washing bottle through the nozzle and rotates at the same time. When the water inlet hole of the lower valve body is connected, the water is pressurized through the nozzle to flush the inside of the bottle.

technical parameter

Production efficiency: 1200 bottles / h

Suitable bottle height: 120-300 mm

Applicable bottle diameter: 40-90mm

Rated power: 0.37kw/380v

Water consumption: 1m3 / h

Weight: 140kg
