Hx-14 siphon filling machine
Scope of application
It is used for filling wine, soy sauce, vinegar and other liquids
Product description
1. No filling without bottle filling, set the liquid level to stop filling automatically, and the inherent fragrance of liquid does not overflow;
2. The filling plug will never fall off and will not flow back.
3. It is easy to use and does not need to suck. Before the first use, it only needs to put down the filling nozzle to form siphon can.
4. A variety of different sizes of nozzles to meet customer requirements for production.
technical parameter
Number of filling heads: 14 (18 and 24 can be customized) | Motor power: 0.37kw |
Production efficiency: 800-1600 bottles / h (500ml) | Filling capacity: 50-3000ml |
Filling accuracy: ± 1.0mm | Mouth diameter: 12-30mm |
Equipment size: 900 * 900 * 1600mm | Weight: 100kg |
