Hx-14 siphon filling machine

Update time:2020-01-13 10:26:23 Hits:1299

Hx-14 siphon filling machine

Scope of application

It is used for filling wine, soy sauce, vinegar and other liquids

Product description

1. No filling without bottle filling, set the liquid level to stop filling automatically, and the inherent fragrance of liquid does not overflow;

2. The filling plug will never fall off and will not flow back.

3. It is easy to use and does not need to suck. Before the first use, it only needs to put down the filling nozzle to form siphon can.

4. A variety of different sizes of nozzles to meet customer requirements for production.

technical parameter

Number of filling heads: 14 (18 and 24 can be customized)

Motor power: 0.37kw

Production efficiency: 800-1600 bottles / h (500ml)

Filling capacity: 50-3000ml

Filling accuracy: ± 1.0mm

Mouth diameter: 12-30mm

Equipment size: 900 * 900 * 1600mm

Weight: 100kg
