Fzd-12 negative pressure filling machine
Scope of application:
It is mainly used for filling wine, soy sauce, vinegar and so on.
Product Description:
1. Vacuum suction can absolutely ensure no dripping and foaming, and can avoid the bottle mouth thread and label mildew caused by liquor overflow. It is especially suitable for the irrigation of wine, health wine, juice beverage, soy sauce, vinegar and other liquids with low concentration and easy foaming.
2. Low vacuum, vacuum degree of 0.01 MPa, does not affect the flavor of the wine.
3. It is easy to adjust and use quick change structure without tools. The liquid level error is less than 2mm. It is especially suitable for multi bottle production.
4. Bottle holder buffer and overload protection ensure the reliability and stability of filling.
Fzd series technical parameters:
model | FZD-12 | FZD-18 | FZD-24 |
Number of filling heads | 12 | 18 | 24 |
throughput | 2400 bottles / hour | 3500 bottles / h | 5000 bottles / hour |
Applicable bottleneck | 40-90mm | ||
Suitable bottle height | 120-320mm | ||
power | Electric shock 0.75kw | Electric shock 0.75KW | Electric shock 0.75KW |
Dimensions | 1200*1000*1900mm | 1400*1200*1900mm | 1600*1300*1900mm |
weight | 950KG | 1200KG | 2000KG |
Filling volume | 100-1500ml |
